Public Safety Transportation Network Interconnection and Enhancement Solutions
Programmatic background
With the gradual advancement of the concept of autonomous driving and smart car, people have higher requirements on the interactivity, intelligence and interconnectivity of cars. Today, most automobile manufacturers and suppliers generally integrate GNSS positioning function with other signals such as radio, TV, Bluetooth, Wifi into the car, including Bosch, Continental, Delphi, Marelli, Mitsubishi, Volkswagen, FAW, etc. The whole system will need antennas for external gain and expansion. The entire system will require antennas for external gain and extension, and how to combine these components in a compact, efficient and cost-effective way is a key issue.
demand analysis
Limited roof space
Needs to be compact and aesthetically pleasing
Post-applications want as much as possible
Fewer holes for easy loading and unloading
The interference between antennas should be guaranteed to be more than 12dB.
Forward-looking in terms of new technologies and band expansions in various communication technologies.
(Support 5G new band and WIFI 6E)
The rail industry needs a higher
Requirements and Certifications
Program Introduction
Macronix in-vehicle antenna solutions for automobiles, rail transit and ferries are complete and comprehensive interconnection and enhancement solutions for public safety transportation networks, supporting the use of
GNSS signals, WIFI signals, 5G LTE signals, radio and TV signals for full coverage and future expansion. Provides multiple types of installation methods and locations.
Suitable for different applications on different vehicles to bring the best connection and signal quality.
Program Configuration
1. High-performance combination dome antenna on the roof of the car
TS-LGMM
-
Up to 4x4 MiMo 4G/5G antennas
(6000MHz) - Up to 6x6 MiMo WiFi6E
-
Support GPS/GNSS antenna
(26dB gain) - Single-hole mounting on metal or plastic tops
- Good isolation and correlation coefficients
- Conforms to IP69k/IK10
2. High-performance combination shark fin antenna on the roof of the car
TS-SHKG/GPSD
-
Up to 4x4 MiMo 4G/5G antennas
(6000MHz) -
Up to 4x4 MiMo WiFi6E
(2.4/5.0/7.1 GHz) -
Up to 4 GPS/GNSS antennas
(26dB gain) - Support external VHF, UHF and other additional antennas
- Single-hole mounting, beautiful shark fin design
- Good isolation and correlation coefficients
- Conforms to IP69k
3. Fully certified high reliability combination antenna for rail transportation
TS-TRNM
- Compliance with all rail industry certifications
- Up to 4*4 MIMO 5G/ WIFI
- GNSS support
- High gain and directionality
- Maximum power 60W
- Four-hole installation, stable and reliable
4. Hidden combination antenna inside the instrument panel
TS-BATGM
-
Up to 2x2 MiMo 4G/5G
(6000MHz) - Up to 2x2 MiMo WiFi
-
Support GPS/GNSS antenna
(26dB gain) - Concealed interior installation
5. Front windshield antenna
TS-EF
-
4G/5G SiSo antenna
(6000MHz) - Gain up to 6dBi
- Portable antenna, plug and play
- Can be mounted on non-conductive surfaces
- IP55 compliant and weather resistant
6. High gain roof-mounted GNSS antenna
TS-GPS25P
- Supports global GNSS systems
-
L1/L2/L5 antennae
(1136-1300, 1559-1612 MHz) - Multi-band, multi-constellation operation
- Provides 37dB gain LNA
- Excellent filtering effect
Program Advantage
The Public Safety Transportation Network Interconnection and Enhancement Solution offers high flexibility and modularity to provide the same connectivity stability for different vehicle models and brands, with up to 6 * 6 MIMO 5G + 6 * 6 MIMO WIFI6E + GNSS in a single compact antenna, and more than 13 components in one antenna, to adapt to different application scenarios and connectivity requirements.
Support LTE + GNSS +WIFI
High Compactness
Space Saving
Single Hole Installation
Preserving the value of your vehicle
stable
In-vehicle connection
Flexible installation
Approach and Location
Applications & Industries
- Public Safety and Transportation
- Fleet Management
- In-vehicle communication and entertainment systems
- Smart Cars and V2X
- Railroad and Railway Transportation
Practical application effect demonstration
Caravan communication and entertainment with MIFI (mobile WIFI)
Applications
public security
Applications
Automatic Driving and Smart Cars
Applications
Related Products
High Performance Dome Antennas for Car Roofs
HH-LGMM
- GPS/GNSS antenna support (26dB gain)
- Single-hole mounting on metal or plastic tops
- Good isolation and correlation coefficient
- Conforms to IP69k/IK10
Roof-mounted high-performance combination sharkfin antennae
HH-SHKG/GPSD
- Support for external VHF, UHF and other additional antennas
- Single-hole mounting, beautiful shark fin design
- Good isolation and correlation coefficient
- Conforms to IP69k
Fully Certified High Reliability Combination Antenna for Railway Transportation
HH-TRNM
- Compliance with all rail industry certifications
- GNSS support
- High gain and directionality
- Four-hole installation, stable and reliable
Hidden combination antenna inside the instrument panel
HH-BATGM
- Up to 2x2 MiMo 4G/5G (6000MHz)
- Up to 2x2 MiMo WiFi
- GPS/GNSS antenna support (26dB gain)
- Hidden interior installation
Front Windshield Antenna
HH-EF
- Gain up to 6dBi
- Portable antenna, plug and play
- Can be mounted on non-conductive surfaces
- IP55 compliant, weather resistant
High Gain Roof Top GNSS Antenna
HH-GPS25P
- Supports global GNSS systems
- Multi-band, multi-constellation operation
- Provides 37dB gain LNA
- Excellent filtering effect
