TSN Time Sensitive Network
Time Sensitive Networking (TSN) can control and prioritize the data flow in an Ethernet network to ensure system real-time performance and reliability based on the requirements of different applications such as guaranteed bandwidth, time synchronization and low latency.
What is TSN?
Time Sensitive Networking (TSN) is an emerging networking technology designed to enable efficient real-time communication.TSN is based on the IEEE standard and provides a set of protocols and mechanisms designed to ensure that data in a network is transmitted within tight latency and reliability limits. This technology is particularly well suited for the Industrial Internet of Things (IIoT) environment, where IIoT systems are typically comprised of intelligent infrastructure and hyperconnected devices with sensing, processing, and networking capabilities that generate large amounts of data and share the same network. In such environments, reliable delivery of real-time and mission-critical messages is critical, regardless of other network traffic, and TSN technology is designed to address these challenges, improving system efficiency, reliability and security.
Benefits and Features of the TSN Standard
Time Synchronization
TSN is equipped with a time synchronization mechanism that ensures all devices in the network use the same time base, guaranteeing consistency and accuracy of data transmission, which is crucial for industrial equipment that needs to work in tandem.
Bandwidth Protection
Through the bandwidth guarantee mechanism, TSN ensures sufficient bandwidth for different types of data streams to avoid data loss or delay due to traffic congestion.
Flow Scheduling
TSN provides a traffic scheduling mechanism that enables the network to more flexibly manage the transmission sequence and frequency of multiple data streams, optimizing the use of network resources.
Data transmission priority control
This mechanism ensures that real-time sensitive data is transmitted first, thus minimizing data transmission delays.
Honghong TSN Solution
Honghong provides you with a variety of TSN solutions to help you quickly perform complex tasks such as TSN testing.
TSN Flow Scheduling Controller
The package enables the data flow volume from the traffic generator to be transmitted under the QBV protocol scheduling, which enables the characterization of ST plan traffic. The duration, bandwidth size and priority of different data flows can be specified.
- Supports QBV protocol scheduling
- Controlling data stream prioritization
- For industrial automation environments
Small Scale E-Learning Package
Provides transceiver testing for small-scale TSN networks and supports simulation and analysis of various TSN standards (e.g., QBV, QAV, etc.). Suitable for research and education.
- Supports multiple TSN standard simulations
- Easy to set up and use
- Suitable for educational and research environments
Large Scale Network Planning Kit
The package provides multi-parameter tuning to support different TSN technology configurations and tests, which is suitable for the design and deployment of large-scale network environments.
- Supports multiple TSN technology configurations
- Provides automated testing options
- Ideal for large industrial network deployments
TSN Interoperability Validation System
It can satisfy the user's need to verify TSN protocols in heterogeneous equipment networks and supports flexible network configuration and testing.
- Support TSN protocol testing for heterogeneous devices
- Flexible network configuration options
- Suitable for product testing and validation environments
TSN Control System
Provides centralized control and management of TSN network devices and supports multiple network configuration protocols (e.g., VLAN, MAC, etc.), which is suitable for all types of network operation scenarios.
- Centralized control of multiple TSN devices
- Supports VLAN, MAC and other configuration protocols
- For Enterprise Network Management
Hong Hong TSN Hardware Standard
Honghong's TSN time-sensitive network hardware product line includes a wide range of TSN devices such as TSN boards, TSN switches, TSN loggers, etc., which can help you quickly deploy TSN technology. In addition, Honghong has also launched TSN IP cores that can be used to develop TSN-enabled switches and endpoint devices to help you with your development.
RELY-TSN4
4-Port 1G Time-Sensitive Network Switch
Equipped with 4/12/20 multimedia Gigabit Ethernet ports and 1 internal port for seamless and reliable Ethernet, the RELY-TSN-BRIDGE supports most of the TSN standards and demonstrates excellent reliability in demanding scenarios such as railroad, aerospace, automotive and industrial automation.
RELY-TSN12
12-Port 1G/10G Time-Sensitive Network Switch
The RELY-TSN12 provides 8 copper ports and 4 multimedia ports to support various TSN standards. The built-in web server simplifies management and is suitable for industrial verification, automation, secure communication and many other applications.
RELY-TSN20
20-Port 1G/10G Time-Sensitive Network Switch
The RELY-10TSN20 is the most versatile TSN switch in Relyum's industrial lineup, offering four 10GBASE-SFP multimedia ports, eight TSN copper ports, and eight regular Ethernet ports, and supporting a wide range of TSN standards for high versatility.
RELY-TSN-REC
Time Sensitive Network Traffic Logger
The device is capable of inspecting, timestamping, and logging regular Ethernet and time-sensitive network traffic using the same IEEE 802.1AS timing references as the other devices on the network being analyzed.
RELY-TSN-LAB
Time Sensitive Network Test Tool
The device allows measurement of bandwidth and delay for certain traffic in a particular device or network segment. This can be performed by hardware time-stamping packets before they are injected into the network or device to be analyzed and after they are received from the network or DUT.
RELY-TSN-PCIe
Time Sensitive Network Endpoint Bridge PCIe NICs
The device can be used as a PCIe TSN endpoint and a TSN bridge providing 2 multimedia Gigabit Ethernet ports and 2 internal ports. As an endpoint, it offers the possibility of integrating TSN technology into a deterministic network, which can be introduced in the device hosting it.
Honghong TSN Application Areas
Industrial
Industrial Manufacturing Systems, Industrial Robotics
Rail Transportation
Train Communication Network
automobile
Self-driving cars, in-vehicle networks
airspace
Avionics
Media Transmission
Highly real-time transmission and processing of images and audio
