HONGKE's TSN switch realizes reliable technology for deterministic Ethernet!

Time Sensitive Networking (TSN) combines the OT and IT worlds and ensures interoperability and standardization of all devices in a deterministic Ethernet network. This technology significantly reduces equipment investment, maintenance, seamless integration of advanced analytics services, and reliance on a single vendor.All these advantages make time-sensitive networks the reference technology in future Ethernet networks.


HONGKE RELY-TSN-BRIDGE TSN switches for seamless implementation of deterministic Ethernet.The device offers 4 multimedia Gigabit Ethernet ports and 1 internal port, making it compatible with other products on the market. Thanks to the RELY-TSN-BRIDGE's high degree of adaptability to most TSN standards on the market, the device is suitable for any specific profile and demonstrates perfect reliability in technically demanding industrial application scenarios such as railroads, aerospace, automobiles and industrial automation.

RELY-TSN-BRIDGE TSN Switches: Realizing the convergence of OT and IT worlds

---------- Product Key Features --------- -

Hongke RELY-TSN-BRIDGE TSN 4-Port Switch

I. Communication Technology

1. 4 Ethernet ports

2. Dielectric option (SFP fixed frame):

  • 10/100/1000Base-T
  • 1000Base-X
  • 100Base-FX

3, 1 10/100/1000 BaseTX Ethernet service port

4、RSTP IEEE802.1w

5、LLDP support

6. VLAN support

7. Based on Ethernet type or IEEE 802.1P traffic priority.

8、1 USB port

II. TSN Functions

1, IEEE 802.1AS - Timing and Synchronization

2. IEEE 802.1Qbv - Enhancement of Program Traffic

3. IEEE 802.1Qav - Forwarding and Queuing Enhancement for Time-Sensitive Streams

4. IEEE 802.1Qcc - Enhancement of Stream Retention Protocols

5. IEEE 802.1Qci * - Per-stream filtering and management

6, IEEE 802.1CB * - Reliable Frame Duplication and Cancellation

7. IEEE 802.1Qbu * and IEEE 802.3br * - Reliability of frame duplication and cancellation

III. Performance and Configuration

1. On-board UltraScale™ FPGA for high-speed network switching and PTP timestamping

2. Multi-core CPU units support autonomous software applications.

3. SNMPv3, SSH, Netconf support

4. Web-based HTML5-GUI access/configuration:

  • Accessible via HTTP(S)
  • Profile Configuration and Firmware Updates
  • Real-time network monitoring

*In interoperability testing

Hardware parameters

1. Fanless design and all-metal casing

2、Source: 6VDC to 30 VDC

3. Operating temperature: -40°C to + 70°C

4、Storage temperature: -40°C to + 85°C

5、Optional Mounting: DIN Rail
