Open Source Platform for the Energy Industry
RevPi Flat module
demand (economics)
Today's energy industry faces enormous challenges.Renewable energy, electric vehicles and grid expansion are just some of the buzzwords in political, media and social discussions.In addition, the liberalization of the electricity market and the resulting increase in competition, as well as digitization, have brought about entirely new structures and business models.
RevPi Flat
The module is based on the Raspberry Pi and features true industrial suitability and a large number of interfaces. Due to the open platform concept (including full root access), the device guarantees maximum design freedom when realizing projects.
RevPi Flat comes with a Trusted Platform Module (TPM). In addition, we add a micro usb socket for uploading new software images.
Reforming the Energy Sector
RevPi Flat application scene:
Modern, Decentralized Energy Management
Virtual Power Plant
Provides balanced power/control power range in the control of small power plants
Energy Trading
Control of charging stations and hydrogen batteries
Electric Vehicle Cost and Time Optimization Charging / Charge Time Optimization
Management of temporary energy stations, e.g. electric vehicles
Single-site management of digital master data, documents and maintenance protocols
Remote monitoring of data
Cloud Solutions
IT Security and Trusted Platform Module (TPM)
RevPi Flat forms a versatile, Raspberry Pi and linux based, freely programmable platform for process optimization, more efficient data processing and the implementation of new marketing strategies in the energy industry. In addition, we offer you a comprehensive range of services such as programming, sensor selection and more.
Parameter Specifications
| Technical Indicators | |
|---|---|
| processors | Broadcom BCM2837B0 with Quad-Core ARM Cortex-A53 |
| Clock Frequency | 1.2 GHz |
| Memory | 1 GB |
| eMMC Flash Memory | 8 GB |
| Power supply | 24 V DC (10.8...28.8 V DC) |
| Maximum power consumption | 16W |
| Housing Type | DIN rail housing |
| Shell Material | Polycarbonate Fiber |
| Dimensions (H x W x D) | 90 x 106 x 70 mm |
| weights | Approx. 248g |
| Protection Level | IP20 |
| Working Temperature | -20°C...+ 55°C |
| Storage Temperature | -40°C...+ 85°C |
| Humidity | 93% |
| EMC interference emission | Conforms to EN 61000-6-4 |
| EMC immunity | Conforms to EN 61000-6-2 |
| CE, RoHS certified | 有 |
| connector |
|---|
| 4 RJ45 100/Gigabit Ethernet ports |
| 2 USB A sockets |
| 1 × RS485 terminal (spring terminal) |
| 1 × RS485 terminal (rj45 socket) |
| 1 digital input |
| 1 analog output (0-10V DC) |
| 1 analog input (0-10V DC) |
| 1 Wifi |
| 1 ISM 868mhz (SMA socket) |
