EtherCAT Slave – PROFINET-IRT FO Device
Anybus X-gateway讓您可以在EtherCAT和Interbus網絡之間無縫內部連接PLC控制系統以及它們所連接的設備。
Fast copying of I/O data
The main function of the X-gateway is the fast transfer of cyclic I/O data between two networks. This eliminates the need for additional calculation work by your PLC. The gateway acts as a slave on both networks. The data transfer is completely transparent and has a maximum data capacity of 512 bytes in each direction.
Easy to configure - no programming required!
The connection between the two networks is quickly established using the Anybus Configuration Manager software included in the X-gateway. No programming skills are required for the gateway setup. This is because the X-gateway is factory defaulted with a predefined I/O size of 20 bytes.
Description
Features and Benefits
- Fast recovery of cyclic I/O data between two networks (10-15 ms)
- Validated and tested by all PLC manufacturers
- Supports up to 512 bytes of input and output data in each direction.
- By using data from other connected devices, it is possible to create web pages that display and control processes at the plant level.
- Fast, dynamic transfer of fieldbus data to Microsoft Windows-based SCADA/HMI/enterprise systems via the included Anybus OPC Server
- Optional control and status information can be added to the I/O data for diagnostic purposes.
- Rugged, self-contained housing for use in harsh industrial environments
- Free worldwide technical support and consultation
EtherCAT從站接口
EtherCAT從站設置可通過導入提供的.XML文件到控制PLC的工程工具來實現。
- 完整的EtherCAT從站功能根據DS 301 V4.022
- 支持EtherCAT之上的CANopen
- 最大512字節輸入數據和512字節輸出數據(PDO + SDO)
- 波特率100 Mbit/s全雙工
- 4 FMMU通道(可被EtherCAT主站自由用於任何目的)
- 4 SM通道
- 面向位的FMMU操作
- 位置地址分配，節點地址分配和邏輯地址分配
- PDI看門狗(Watchdog)
- 輸出I/O同步管理器看門狗(Watchdog)
- 集成交換機，支持菊花鏈拓撲
- 2x RJ45 EtherCAT連接件
PROFINET IRT光纖設備/從站接口
PROFINET IRT光纖設備/從站設置可通過內置web界面完成，或者通過導入提供的.GSDML文件到控制PLC的工程工具來實現。
- 完整的PROFINET-IRT等時同步實時(IRT)通訊
- 最大220字節輸入數據和220字節輸出數據
- 非循環數據交換(記錄數據請求)
- 高達17槽/ 高達4子槽每個槽(默認1t)
- 波特率100 Mbit/s固定
- 集成的FTP服務器通過使用標準的FTP客戶端實現簡單的文件管理
- Web服務器具有動態數據能力以及服務器端包含(SSI)能力
- Email客戶端具有動態數據能力，並可通過事件觸發email處理
- 內置文件系統，具有每個用戶的安全框架
- SNMP-MIBII Support
- Modbus-TCP服務器(只讀)
- TCP/IP configuration via DCP (Discovery and Configuration Protocol)
- LLDP (Link Layer Discovery Protocol)
- Support for I&M (Identification and Maintenance)
- PROFINET uplink configuration via .GSDML file
- 集成交換機，支持菊花鏈拓撲
- 同時具有2x SC-RJ光纖網絡連接件
- 支持PROFINET RT和IRT功能規範2.3
- Undergoes conformance testing and supports Class A, B and C.
Technical Specifications
| Dimensions (L-W-H) | 114 x 44 x 127mm or 4,49 x 1,73 x 5,00″ |
| Weight | 400g or 0,880 lbs |
| Operating temperature | -25 to +65 °C or -13 to +149 °F |
| Storage temperature | -40 to +85 °C or -40 to +185 °F |
| Power supply | 24 VDC +/- 20% via 2-pole 5.08 mm Phoenix pluggable screw connector |
| Current consumption | max. 400mA (Typical 200mA) |
| Enclosure material | Aluminium and plastic |
| Installation position | Vertical / Flat* |
| Galvanic isolation | YES, on both BUS/Ethernet side |
| Mechanical rating | IP20, NEMA rating 1 |
| Mounting | DIN-rail (EN 50022 standard) |
| I/O configuration | via USB port with Anybus Configuration Manager software |
| Certifications | CE., CULUS, RoHS |
Ordering Information
| Order Code | AB7970 |
|---|---|
| Deliverables | Gateway Quick Start Documentation USB Configuration Cable 不 Includes power supply Configuration software available for download |
Warranty: 3 years. For purchase instructions and terms and conditions, please contactsupport@hongtronics.com
