CAN-CR200 repeater
Function Overview:
The Ixxat CAN-CR200 Repeater with Trunk Bus, a CAN repeater with two CAN interfaces and a CAN trunk interface, increases the CAN bus loading capacity, creates physical coupling of the bus system and provides current isolation. Multiple repeaters can be easily arranged and connected via an integrated DINrail bus to create a variety of topologies and optimize network structure.
Description
Products
Features and Benefits:
- Designed for industrial environments, they meet high requirements for ruggedness, temperature range and safety for demanding applications.
- Provides flexible CAN network design with support for short, star and tree topologies to optimize network structure.
- Fast and transparent operation, realizing line lengths of about 40 meters (200 ns delay), compatibility with all high-level protocols, and minimal impact on real-time behavior.
- Simplified cabling design reduces the number of cables, lowers installation and maintenance costs, and improves efficiency.
- Enhances network reliability by providing electrical isolation up to 1 kV to protect equipment from voltage spikes.
- Automatic network monitoring and fault recovery, disconnecting affected network segments and restoring them automatically after the fault is removed.
- Supports backbone bus design to realize tree or star topology and enhance connectivity by cascading multiple repeaters.
- Integrated 120 ohm bus terminal resistor prevents reflections at the end of the line to ensure stable communications.
Deliverables: CAN Repeater, User's Manual
- Net width: 100 mm
- Net height: 118 mm
- Net depth: 22.5 mm
- Net weight: 136 grams
Power & Current
- Current consumption type: 41 mA
- Maximum current consumption at rated Vcc: 100 mA
- Input Voltage: +9V to +32V DC
- Isolation: 1 kV DC 1 sec.
Operating Temperature Range
- Minimum operating temperature: -20°C
- Maximum operating temperature: 70°C
- Storage temperature range: -40°C to 85°C
- Relative humidity: 10 to 95 %, non-condensing
makings
- Housing material: Polyamide housing for top hat rail mounting
- Packaging material: cardboard
- Warranty period (years): 1 year
- CE certification: Yes
- U.S. FCC Certification: Yes
- Waste Electrical and Electronic Equipment (WEEE) Category: IT and Telecommunications Equipment
- Protection level IP: IP30
- Connectors: 2 x D-Sub 9 Connectors, 1 x Backbone Bus, 1 x Power Connector
- Pool included: No
- CAN Mode: CAN High Speed with CAN Choke (ISO 11898-2)
- CAN Transceiver: TI SN65HVD251
- CAN baud rate: up to 1 Mbit/s
Products
| PRODUCTS | Order Number | CAN/CAN FD channels | Current isolation | CAN Terminal Resistance | Connectors |
|---|---|---|---|---|---|
| CAN-CR100 | 1.01.0210.20000 | 2 x CAN HS (switchable to CAN FD) | yea | yea | 2 screw terminals |
| CAN-CR100 | 1.01.0210.20200 | 2 x CAN HS (switchable to CAN FD) | yea | 不 | 2 screw terminals |
| CAN-CR110/FO | 1.01.0210.11020 | 2 x CAN HS (switchable to CAN FD) | yea | yea | 1 x screw terminal 1 x Fiber Optic (F-SMA) |
| CAN-CR110/FO | 1.01.0210.11220 | 2 x CAN HS (switchable to CAN FD) | yea | 不 | 1 x screw terminal 1 x Fiber Optic (F-SMA) |
| CAN-CR120/HV | 1.01.0210.20010 | 2 x CAN HS (switchable to CAN FD) | Yes (3 kV) | yea | 2 screw terminals |
| CAN-CR120/HV | 1.01.0210.20210 | 2 x CAN HS (switchable to CAN FD) | Yes (3 kV) | 不 | 2 screw terminals |
| CAN-CR200 | 1.01.0067.44010 | 2 CAN HS | yea | switchable | 2 x D-Sub 9 1 x DIN rail bus |
| CAN-CR210/FO | 1.01.0068.45010 | 2 CAN HS | yea | switchable | 1 x D-Sub 9 1 x Fiber Optic (F-SMA) 1 x DIN rail bus |
| CAN-CR210/FO | 1.01.0068.46010 | 2 CAN HS | yea | switchable | 1 x D-Sub 9 1 x Fiber Optic (ST) 1 x DIN rail bus |
| CAN-CR220 | 1.01.0067.44400 | 2 CAN HS | Yes (4 kV DC/3.5 kV AC) | switchable | 2 D-Sub 9 |
| CAN-CR220 | 1.01.0067.44300 | 2 CAN HS | Yes (4 kV DC/4 kV AC) | switchable | 2 D-Sub 9 |
| CAN-CR300 | 1.01.0210.40000 | 4 x CAN HS (switchable to CAN FD) | yea | yea | 4 screw terminals |
| CAN-CR300 | 1.01.0210.40200 | 4 x CAN HS (switchable to CAN FD) | yea | 不 | 4 screw terminals |
