【Pico診斷案例】高檔車在P檔和N檔怠速噪音異常
如何解決高檔車再P檔以及N檔怠速噪音異常的問題?來源是宏虹Pico技術工程師，給客戶做技術支持時遇到的故障問題，整理後來分享給大家學習。本篇會介紹利用Pico NVH套裝示波器，診斷故障原因以及分析過程，最後還會說明是如何將故障排除。輕鬆的搭配圖表，利用短短的幾分鐘了解一篇技術案例。
MTBF Calculation of Programmable Switching Module by Pickering
In the case of Pickering's BRIC matrices, for example, one model contains 2238 relays. Of these, 2208 are matrix bodies, 24 are isolation relays, and 6 are standby relays (accessories are not involved in the operation and can be excluded from the MTBF calculation). According to the working principle of the product, the isolation relays automatically follow the matrix relay, and in most applications their switching frequency is equal to or slightly lower than that of the matrix relay, so there is no need for a separate calculation.
【Pico診斷案例】2012款Jeep 大切諾基發動機無法啟動
一輛2012款 Jeep大切諾基，搭載3.6L發動機，累計行駛里程約19萬km，車主反映，發動機無法啟動。利用pico示波器從 EPS處測量 CAN C總線的通訊波形（圖1），發現 CAN C-L信號偶爾上翻，說明 CAN C-L線斷路。故障排除:用焊錫把接點 S358焊好後試車，發動機啟動、運轉均正常，故障排除。
Product Solution] Why do people choose Spectrum to measure machinery? (I)
When using a modular digitizer to measure mechanical equipment, a variety of sensors are required to facilitate the conversion of mechanical parameters (such as force, acceleration, pressure, speed, etc.) into electrical signals that you can test. The key to choosing a digitizer is to have enough bandwidth, number of channels, and dynamic range to handle the sensors. digitizerNETBOX with 16-bit resolution supports a dynamic range of 96 dB and provides up to 16 analog input channels.
【Pico診斷案例】2006款BMW 730Li 發動機怠速抖動
一輛2006款BMW 730Li，搭載N52B30BF發動機，累計行駛里程約為24.6萬km。該車發動機怠速抖動，發動機故障燈異常點亮，且進氣管處有輕微的回火聲。利用Pico示波器來診斷異常，若只單純做壓力測試是無法發現異常的，因此也要進行汽缸壓縮壓力測試，可以大大提升診斷效率。
